Rated capacity (ah): 10Ah ; 12ah ; 14Ah
Technical description: 3.7 V 40x 18650
Cell combination: 10-series 4-parallel
Battery size: 380*38*70mm
Number of cells (parallel * series): 40 pcs.Â
Discharge voltage (V): 30 +/- 1 V
Charge voltage (V): 42 V
Built in 30A BMS with balance function, over-discharge, overcharge protection, temperature senson
Rated discharge current (a): 15а
Instantaneous maximum discharge current (a): 30A
Maximum Continuous Discharge Current (A): 15a
Battery weight: about 2kg
